Antec C5 ARGB Constellation Series ATX Mid Tower Gaming Cabinet (Black)

Constellation Series ARGB ATX Mid Tower — 270° Seamless Tempered Glass Front & Side, Dual-Chamber Layout with Back-Connect Support, Vertical Cooling with Up to 10 x 120mm Fans, Pre-Installed 7 x ARGB PWM Fans with Built-in Fan Controller, Simultaneous Top & Bottom 360mm + Side 280mm Radiator Support, USB Type‑C 3.2 Gen 2 Front I/O, 95mm Cable Management Space, ATX / Micro‑ATX / Mini‑ITX Support.

The Antec C5 ARGB Black is a flagship Constellation Series mid-tower designed around vertical cooling and modern “back‑connect” motherboard layouts, using a dual-chamber design with a top‑mounted PSU and a dedicated rear cable routing chamber for an ultra‑clean front view.[web:1513][web:1514][web:1524] Seamless tempered glass front and side panels with a 45° bevel create a 270° uninterrupted panoramic view, highlighted by an ARGB front lighting strip and seven pre-installed ARGB PWM fans.[web:1513][web:1517][web:1521]

A vertical bottom‑to‑top airflow scheme supports up to 10 x 120mm fans, while water‑cooling support is exceptional: simultaneous mounting of 360mm radiators at the top and bottom plus a 280mm radiator on the side allows extreme liquid‑cooled builds.[web:1513][web:1517][web:1521] A removable HDD cage, magnetic dust filters and a USB Type‑C 3.2 Gen 2 front port round out a feature‑rich, enthusiast‑grade chassis.[web:1513][web:1517][web:1521]

>270° seamless tempered glass — Front and side tempered glass panels with 45° bevel and minimal joint gap deliver an uninterrupted panoramic view of your hardware.[web:1513][web:1521][web:1524] >Stylish ARGB front lighting strip — Tool‑free front panel with integrated ARGB light strip adds a distinctive Constellation‑series aesthetic.[web:1513][web:1517][web:1521] >Dual‑chamber design — PSU and cable routing are isolated in the right/top chamber, leaving the main chamber clean for airflow and component display.[web:1513][web:1514][web:1521] >Back‑connect motherboard support — Fully supports next‑gen back‑connect motherboards; plug cables in from the back for a cleaner front and smoother airflow channel.[web:1513][web:1514][web:1524] >Vertical cooling up to 10 fans — Vertical bottom‑to‑top airflow scheme can accommodate up to 10 x 120mm fans for very high heat dissipation capacity.[web:1513][web:1517][web:1521] >Pre-installed 7 x ARGB PWM fans + controller — 6 reverse‑flow ARGB PWM fans on side and bottom for massive intake + 1 standard ARGB PWM rear exhaust, all controlled via a built‑in ARGB + PWM fan hub.[web:1513][web:1517][web:1521] >Triple‑radiator water‑cooling support — Simultaneous support for 360mm radiators at the top and bottom and a 280mm radiator on the side for extreme water‑cooling builds.[web:1513][web:1517][web:1521] >Magnetic dust filters — Magnetic filters on top and bottom provide dust‑free air intake and easy cleaning; additional filtering on front/bottom depending on configuration.[web:1513][web:1516][web:1519] >Removable HDD cage & flexible storage — Removable HDD cage offers 1 x 3.5" HDD + 2 x 2.5" SSD bays; bottom of the case can host an extra 3.5" HDD (after removing frontmost bottom fan) or a 2.5" SSD (after removing lowest side fan).[web:1513][web:1516][web:1519] >USB Type‑C 3.2 Gen 2 front I/O — High‑speed front panel connectivity via USB‑C 3.2 Gen 2 plus twin USB 3.0 ports for modern peripherals and external storage.[web:1513][web:1521][web:1524]

--- ## Specifications ```html [2][3][4] [1][3] [3][1] [5][6][1] [7][1][3] [6][3] [1][3][6] [3][6] [8][7][1] [6][3] [3][6] [6][3] [2][1][3] [1][2][3] [2][1][3] [1][2][3] [2][3][1] [8][7][1] [3][1] [9][2][3]

Spec	Detail
Model	Antec C5 ARGB Black (Constellation Series)
SKU	C5-ARGB-BLACK
Color	Black
Form factor	Mid Tower
Materials	Steel + Plastic + 4mm Tempered Glass
Motherboard support	ATX, Micro‑ATX, ITX (incl. back‑connect boards)
Dimensions (D x W x H)	469 x 285 x 400 mm
Net weight	≈ 7.6 kg
Front I/O	Power, LED button, 2 x USB 3.0, 1 x USB Type‑C 3.2 Gen 2, Audio in/out
Expansion slots	7
Drive bays	1 x 3.5" + 2 x 2.5" (via removable HDD cage), plus optional bottom 3.5"/2.5" positions
Max GPU length	≤ 410 mm
Max CPU cooler height	≤ 160 mm
Max PSU length	≤ 240 mm (including cables)
Fan support (total)	Up to 10 x 120mm fans (vertical cooling scheme)
Pre-installed fans	7 x 120mm ARGB PWM (6 x reverse intake on side/bottom + 1 x rear exhaust)
Radiator support — Top	Up to 360 mm
Radiator support — Bottom	Up to 360 mm
Radiator support — Side	Up to 280 mm
Dust filters	Magnetic filters on top and bottom; additional filtering on intake zones
Cable management space	Up to 95 mm in right/top chamber
Warranty	2 Years
