Computer Case Fans // Fractal Design
Fractal Design Aspect 12 RGB 120mm Case Fan — White Frame (Single Pack)
Technical specification
120mm Addressable RGB Case Fan — White Frame / White Blades, 6 Hub-Mounted Addressable RGB LEDs, 1200 RPM Fixed Speed, 32 CFM / 54.4 m³/h Airflow, Rifle Bearing, Aerodynamic Stator Struts, Trip Wire Blade Technology, ASUS AURA / Gigabyte Fusion / MSI Mystic Light / ASRock Polychrome / Razer Chroma Certified.
The Fractal Design Aspect 12 RGB White Frame is a fixed‑speed 120mm addressable RGB case fan finished entirely in white, delivering clean, bright RGB lighting and reliable airflow for white‑themed or minimalist PC builds.[web:1267][web:1270] Six individually addressable hub‑mounted RGB LEDs are controllable via your motherboard's 5V ARGB header, with certified support for all major RGB ecosystems.[web:1267][web:1270][web:1290]
Aerodynamic stator struts reduce turbulence and Trip Wire technology on the blade edges enhances airflow efficiency, while a rifle bearing keeps acoustics at a quiet 18.3 dBA at the fixed 1200 RPM operating speed.[web:1267][web:1270][web:1285] The chaining ribbon cable design makes multi‑fan cable management cleaner and easier, with 90,000 hours MTTF for long‑term reliability.[web:1267][web:1270][web:1290]
-
>Full white design — White frame and white blades for a seamless look in white and light-themed gaming builds.[web:1267][web:1270][web:1290]
>6 addressable hub RGB LEDs — Six individually addressable RGB LEDs at the hub controlled via 5V 3-pin ARGB motherboard header or compatible controller.[web:1267][web:1270][web:1290]
>RGB ecosystem certified — Compatible with ASUS AURA Sync, Gigabyte RGB Fusion, MSI Mystic Light, ASRock Polychrome Sync and Razer Chroma.[web:1267][web:1270][web:1290]
>Aerodynamic stator struts — Redesigned stator struts reduce turbulence for smoother, quieter airflow compared to standard fan struts.[web:1267][web:1270]
>Trip Wire blade technology — Micro‑scale serrations on blade edges reduce tonal noise and improve aerodynamic efficiency.[web:1267][web:1270]
>Rifle bearing, 90,000 hours MTTF — Quiet and durable rifle bearing with 18.3 dBA noise and 90,000 hours rated life for maintenance‑free operation.[web:1267][web:1270][web:1285]
>Fixed 1200 RPM, 3-pin connector — Constant 1200 RPM via 3-pin connector for straightforward always-on airflow with no PWM tuning needed.[web:1267][web:1270]
>Chaining ribbon cable — White ribbon cable with built-in chaining support allows daisy‑chaining multiple fans to reduce cable clutter.[web:1267][web:1270][web:1290]
| Spec | Detail |
|---|---|
| Model | Fractal Design Aspect 12 RGB White Frame — Single Pack |
| SKU | FD-F-AS1-1208[web:1286][web:1288][web:1290] |
| Fan size | 120 x 120 x 25 mm[web:1267][web:1270] |
| Screw hole pattern | 105 x 105 mm[web:1267][web:1270] |
| Number of blades | 7[web:1267][web:1270] |
| Frame color | White[web:1267][web:1270][web:1290] |
| Blade color | White[web:1267][web:1270][web:1290] |
| LED type | Addressable RGB (5V 3-pin)[web:1267][web:1270] |
| Number of LEDs | 6 hub-mounted addressable RGB LEDs[web:1267][web:1270] |
| Power connector | 3-pin[web:1267][web:1270] |
| Bearing type | Rifle[web:1267][web:1270] |
| Rotational speed | 1200 RPM (fixed)[web:1267][web:1270] |
| Max airflow | 32 CFM / 54.4 m³/h[web:1267][web:1270] |
| Max static pressure | 1.20 mm H₂O[web:1267][web:1270] |
| Noise level | 18.3 dBA[web:1267][web:1270] |
| Fan input voltage | 12V[web:1267][web:1270] |
| Min startup voltage | 7V[web:1267][web:1270] |
| Fan max input current | 0.16 A[web:1267][web:1270] |
| Fan typical input power | 0.96 W[web:1267][web:1270] |
| LED rated voltage | 5V[web:1267][web:1270] |
| LED rated current | 0.3 A[web:1267][web:1270] |
| LED rated input power | 1.5 W[web:1267][web:1270] |
| MTTF | 90,000 hours[web:1267][web:1270] |
| Unit weight | 135 g[web:1270][web:1285] |
| Cable length | 500 mm[web:1267][web:1270] |
| Cable type | White ribbon with chaining support[web:1267][web:1270] |
| UPC (Single) | 843276103552[web:1286] |
| RGB Ecosystem | ASUS AURA, Gigabyte Fusion, MSI Mystic Light, ASRock Polychrome, Razer Chroma[web:1267][web:1270] |
| Warranty | 2 Years[web:1267] |
