Fractal Design Meshify 3 Black TG Light Tint ATX Mid Tower High Airflow PC Case
Technical specification
ATX High-Airflow TG Case — Rockface Mesh Front, 3x Momentum 14 Fans Included, Light-Tinted Tempered Glass Side Panel, Supports E-ATX (277mm) / ATX / mATX / Mini‑ITX, Up to 360mm Front & 280mm Top Radiator, 349mm GPU.
The Fractal Design Meshify 3 Black TG Light Tint is a modern ATX mid‑tower that updates the Meshify formula with improved airflow engineering, Momentum series fans, and a lightly tinted tempered glass side panel to showcase your build. An aerodynamic rockface-inspired mesh front panel, internal air guide, and three Momentum 14 fans with LCP blades and FDB bearings deliver strong, efficient cooling for contemporary GPUs and CPUs while keeping noise in check. With support for E‑ATX motherboards up to 277 mm wide, GPUs up to 349 mm long, CPU coolers up to 173 mm tall, and radiators up to 360 mm at the front and 280 mm at the top, Meshify 3 Black TG Light Tint is ideal for high‑performance gaming and creator systems in a compact footprint. Tool‑less side and top panels, a cable cover, and new cable aligners make building and maintenance straightforward and clean.
- Light-tinted tempered glass — Lightly tinted TG left side panel offers a clear view of your components and lighting while matching the stealthy black exterior.
- Rockface mesh front — Airflow‑optimized front mesh with a new rockface pattern improves intake performance while keeping dust under control.
- Three Momentum 14 fans included — Ships with 3x Fractal Momentum 14 140 mm fans using liquid crystal polymer blades and FDB bearings for high airflow and low noise.
- GPU-focused airflow guide — Internal air guide helps direct fresh air towards the GPU area for better gaming thermals.
- E‑ATX / ATX / mATX / Mini‑ITX support — Supports E‑ATX motherboards up to 277 mm wide along with standard ATX, Micro‑ATX, and Mini‑ITX boards.
- Radiator support — Front support for up to 360 mm radiators and top support for up to 280 mm, plus 120 mm at the rear, with removable brackets for easy installation.
- Component clearance — Fits GPUs up to 349 mm, CPU coolers up to 173 mm tall, and PSUs up to 180 mm long.
- Modern top I/O — Top/front I/O includes 1 x USB Type‑C 20 Gbps, 2 x USB Type‑A 5 Gbps, and a 3.5 mm combo audio jack plus power button.
- Clean cable management — Interior cable cover, new cable aligners, integrated Velcro straps, and 34.5 mm of routing space help maintain a tidy look behind the motherboard tray.
- Tool-less panels — Push‑to‑lock side panels, bottom filter, front panel, top panel, and PSU bracket for quick access.
- Storage support — Two 3.5"/2.5" combo mounts plus two dedicated 2.5" mounts (up to 6 x 2.5" drives total) support typical gaming/creator storage layouts.
- Dust filtering — Easily accessible PSU/bottom filter; front mesh also acts as a primary filter.
- 2‑year warranty — Protected by a 2‑year manufacturer warranty from Fractal Design.
| Spec | Detail |
|---|---|
| Model | Fractal Design Meshify 3 Black TG Light Tint |
| Product code (SKU) | FD-C-MES3A-02 |
| Cabinet type | ATX High-Airflow Mid Tower |
| Color | Black (light-tinted tempered glass side) |
| Motherboard support | E‑ATX (max 277 mm), ATX, Micro‑ATX, Mini‑ITX |
| Side panels | Left: Tempered glass light tint; Right: Steel |
| Pre-installed fans | 3 x Momentum 14 140 mm (front/rear) |
| Total fan mounts | Up to 6 x 120 mm or 5 x 140 mm + 1 x 120 mm (rear) |
| Radiator support | Front: up to 280/360 mm; Top: up to 240/280 mm; Rear: 120 mm |
| Max GPU length | 349 mm |
| Max CPU cooler height | 173 mm |
| Max PSU length | 180 mm |
| 3.5"/2.5" drive mounts | 2 shared (2 x 3.5" or 4 x 2.5") |
| Dedicated 2.5" mounts | 2 (up to 6 x 2.5" total) |
| Expansion slots | 7 |
| Cable routing space | 34.5 mm behind motherboard tray |
| Front / top I/O | 1 x USB Type‑C 20 Gbps, 2 x USB Type‑A 5 Gbps, 1 x audio combo jack, power button |
| Dust filters | Bottom (PSU), front mesh acts as filter |
| Tool-less features | Push‑to‑lock side panels, bottom filter, front & top panels, PSU bracket |
| Case dimensions (L x W x H) | 433 x 229 x 507 mm |
| Dimensions w/o feet/protrusions | 423 x 229 x 483 mm |
| Package dimensions | 596 x 345 x 550 mm |
| Net weight | Approx. 9.0 kg (TG version) |
| Gross weight | Approx. 10.8 kg (TG version) |
| EAN | 7340172707172 |
| Warranty | 2 Years |
