Frame 5000D RS ARGB - White

The Corsair FRAME 5000D RS ARGB White is a fully-modular high-airflow mid-tower PC case featuring four pre-installed RS140 ARGB fans, the revolutionary InfiniRail™ fan mounting system, RapidRoute 2.0 cable management, and extensive cooling support. With triple 360mm radiator capability, top 420mm radiator support, compatibility with reverse-connector motherboards, and E-ATX motherboard support, this FRAME platform case delivers exceptional cooling, stunning ARGB aesthetics, and future-proof modularity in a pristine white finish.

Key Features:

>Four pre-installed RS140 ARGB PWM fans (140mm) with daisy-chain connections for simplified setup >3D-Y Airflow Steel front panel optimized for high airflow with minimal restrictions >InfiniRail™ fan mounting system for flexible fan and radiator positioning >Fully-modular FRAME design allows swappable motherboard trays, front panels, I/O panels, and PSU shrouds >RapidRoute 2.0 pegboard-style motherboard tray with custom mounting points, tie-downs, and cable looms >Top 420mm radiator support plus dual 360mm radiators (front/side) for extreme cooling >Support for up to 14x 120mm or 12x 140mm fans >Compatible with reverse-connector motherboards (ASUS BTF, MSI Project Zero, GIGABYTE Project Stealth) >Integrated GPU anti-sag stabilization arm >ARGB strip built into front I/O panel for extra lighting >Full tempered glass side panel >Supports Mini-ITX, Micro-ATX, ATX, E-ATX motherboards up to 305mm x 277mm >Graphics card clearance up to 450mm >CPU cooler clearance up to 175mm >PSU support up to 250mm >Storage: 6x 2.5" SSD, 2x 3.5" HDD >Ultra-modern front I/O with USB 3.2 Gen 2 Type-C, 4x USB 3.2 Gen 1 Type-A

Technical Specifications:

Model Number	CC-9011310-WW
Series	FRAME 5000D RS ARGB
Form Factor	Mid-Tower ATX
Color	White
Materials	Steel, Tempered Glass, 3D-Y Airflow Steel, Plastic
Included Fans	4x RS140 ARGB PWM Fans (daisy-chainable)
Maximum Fan Support	14x 120mm or 12x 140mm
Radiator Support - Top	420mm, 360mm, 280mm, 240mm
Radiator Support - Front	360mm, 280mm, 240mm
Radiator Support - Side	360mm, 280mm, 240mm
Radiator Compatibility	120mm, 140mm, 240mm, 280mm, 360mm, 420mm
Motherboard Compatibility	Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm)
Reverse-Connector Compatible	Yes
Expansion Slots	8 Horizontal or 3 Vertical
Maximum GPU Length	450 mm
Maximum CPU Cooler Height	175 mm
Maximum PSU Length	250 mm
Drive Bays	6x 2.5" SSD, 2x 3.5" HDD
Front I/O	1x USB 3.2 Gen 2 Type-C, 4x USB 3.2 Gen 1 Type-A, 1x Audio/Mic Combo Jack, ARGB Strip
Side Panel	Tempered Glass
Cable Routing Space	42 mm
Dust Filtration	Front, Bottom, Right Side, Left Side
Dimensions (H x L x W)	542 x 556 x 250 mm
Weight	15.48 kg
Warranty	2 Years

Package Contents:

>FRAME 5000D RS ARGB Case (White) >4x RS140 ARGB PWM Fans (pre-installed) >3D-Y Airflow Front Panel >Tempered Glass Side Panel >GPU Anti-Sag Stabilization Arm >RapidRoute 2.0 Cable Management Components >Mounting Hardware >User Manual

Perfect for high-airflow builds, ARGB enthusiast setups, white-themed gaming rigs, modular customization enthusiasts, and anyone seeking exceptional cooling with future-proof modularity. The FRAME 5000D RS ARGB White features four pre-installed RS140 ARGB fans with daisy-chain connectivity for simplified setup—control all fans through one PWM connector and one ARGB connector on your motherboard. The 3D-Y pattern front airflow panel delivers optimized high airflow with minimal restrictions. Top 420mm radiator support plus triple 360mm radiator capability enables extreme cooling configurations. InfiniRail™ system provides flexible fan positioning. RapidRoute 2.0 pegboard motherboard tray offers custom cable management. Fully-modular FRAME platform allows future upgrades. Compatible with reverse-connector motherboards for ultra-clean builds. ARGB strip in front I/O adds extra lighting. Build a stunning, high-performance white-themed system with superior ARGB cooling.
