HYTE Y70 Touch Infinite (Black Cherry) combines the 70.7 L dual‑chamber Y70 chassis with a 14.9" integrated IPS touchscreen in the bold Black Cherry red‑black colourway, delivering a panoramic showcase build plus an interactive side display for stats, media and custom layouts via HYTE Nexus Touch.
-
>14.9" integrated IPS touchscreen: 682 × 2560 (2.5K) capacitive IPS panel at 60 Hz with 10‑point multi‑touch, 178 PPI, 500 nits brightness and 1000:1 contrast, powered by HYTE Nexus Touch for configurable dashboards, widgets and themes. [web:974][web:969]
>Black Cherry dual‑tone aesthetic: Red‑and‑black Black Cherry finish with 3‑piece panoramic tempered glass shows off your build while matching aggressive gaming setups. [web:1042][web:924]
>4‑slot vertical GPU support: Supports 4‑slot vertical GPUs up to 422 mm long and 105 mm thick using the included PCIe 4.0 x16 luxury riser cable. [web:974][web:924]
>Ginormous cooling capacity: Up to 10 fans and radiators (360/280/240/140/120 mm) on top, side, rear and bottom provide serious airflow and liquid‑cooling options for high‑end components. [web:974][web:924]
>Modern dual‑chamber layout: Dual‑chamber interior with L‑shaped rubber grommet, labelled cable channels and floating storage sleds keeps the glass side clean and maintenance easy. [web:974][web:1042]
| Specification | Detail |
|---|---|
| Brand | HYTE |
| Model | Y70 Touch Infinite |
| Part Number | CS-HYTE-Y70TTI-RB |
| Colour | Black Cherry (Black-Red) |
| Type | Dual Chamber Mid‑Tower ATX / E‑ATX Case with Integrated Touchscreen |
| Exterior Dimensions | 470 × 320 × 470 mm (H × W × D) [web:974][web:924] |
| Volume | 70.7 L [web:974] |
| Materials | Tempered glass, steel, ABS [web:974][web:924] |
| Motherboard Support | Mini‑ITX, mATX, ATX, E‑ATX [web:974][web:924] |
| PSU Support | ATX PSU up to 235 mm length [web:974][web:924] |
| Expansion Slots | 7 half‑height + 4 full‑height vertical (7+4) [web:974][web:924] |
| PCIe Riser | PCIe 4.0 x16 luxury riser (colour‑matched) [web:974][web:924] |
| Max GPU Length | Up to 422 mm (HYTE spec; some touch‑only listings show 390 mm) [web:974][web:924][web:1042] |
| Max GPU Thickness | Up to 105 mm (4‑slot) [web:974] |
| Max CPU Cooler Height | 180 mm [web:974][web:924] |
| Storage Support | 2 × 3.5" HDD or 4 × 2.5" SSD [web:974][web:924] |
| Fan Support – Top | 3 × 120 mm or 2 × 140 mm [web:974][web:924] |
| Fan Support – Side | 3 × 120 mm or 2 × 140 mm [web:974][web:924] |
| Fan Support – Rear | 1 × 120 mm or 1 × 140 mm [web:974][web:924] |
| Fan Support – Bottom | 3 × 120 mm or 2 × 140 mm @ ~32 mm thick [web:974][web:924] |
| Pre‑Installed Fans | None (fanless; add your own) [web:924][web:1044] |
| Radiator Support – Top | 120–360 mm, 140–280 mm up to 68 mm thick [web:974][web:924] |
| Radiator Support – Side | 120–360 mm, 140–280 mm up to 125 mm thick [web:974][web:924] |
| Radiator Support – Rear | 120 / 140 mm [web:974][web:924] |
| Radiator Support – Bottom | Up to 360 mm (depending on PSU/GPU) [web:974][web:924] |
| Front I/O | 1 × USB‑C 3.2 Gen 2, 2 × USB‑A 3.2 Gen 1, 1 × 3.5 mm audio/mic combo [web:974][web:924] |
| Dust Filters | Top, side and bottom removable filters [web:974][web:924] |
| Windowed Panels | 3‑piece panoramic tempered glass front & side [web:974][web:1042] |
| Touchscreen Panel Type | IPS, 14.9" diagonal [web:974][web:969] |
| Touchscreen Resolution | 682 × 2560 (2.5K) [web:974][web:969] |
| Refresh Rate | 60 Hz [web:974][web:969] |
| Brightness | 500 nits [web:974][web:969] |
| Contrast Ratio | 1000:1 [web:974][web:969] |
| Viewing Angle | 80 degrees [web:974][web:969] |
| PPI / Dot Pitch | 178 PPI, 0.007 mm dot pitch [web:974][web:969] |
| Response Time | 30 ms [web:974][web:969] |
| Touch Input | 10‑point multi‑touch (capacitive) [web:974][web:969] |
| Display Inputs | USB 2.0 header, SATA power, DisplayPort [web:974][web:969] |
| Software | HYTE Nexus Touch (for layouts, widgets, wallpapers) [web:974][web:969] |
| Warranty | 4 Years (HYTE spec; some local listings quote 3 Years) [web:974][web:1044] |
| Box Contents | HYTE Y70 Touch Infinite case (Black Cherry), integrated 14.9" IPS touchscreen, PCIe 4.0 riser, display cabling, accessory kit, documentation [web:974][web:1042][web:1044] |
