Description
Stealth dual-fan RTX 5060 — 3840 CUDA Cores, 8GB GDDR7 128-bit 28Gbps, PCIe 5.0 x16 (x8), TORX Fan 5.0 SHADOW cooling, Boost 2527MHz / Extreme 2535MHz, 145W TDP, 1x 8-pin, 3x DP 2.1b + 1x HDMI 2.1b, 550W PSU Recommended.
The MSI GeForce RTX 5060 8G SHADOW 2X OC is a stealth-inspired RTX 5060 built for smooth 1080p and 1440p gaming with a clean, muted aesthetic. Powered by the NVIDIA Blackwell architecture with DLSS 4, 4th-gen RT Cores, and 5th-gen Tensor Cores, it delivers high FPS with AI-accelerated frame generation and low latency through NVIDIA Reflex 2. The dual-fan SHADOW 2X cooler based on TORX Fan 5.0, optimized heatsink, and compact 197mm length make it a great fit for modern mid-tower and mATX builds.
-
>NVIDIA Blackwell (GB206) GPU — 3840 CUDA Cores, 4th-gen RT Cores, 5th-gen Tensor Cores, DLSS 4 Multi Frame Generation, NVIDIA Reflex 2, NVIDIA ACE
>8GB GDDR7 — 128-bit, 28Gbps, 448 GB/s bandwidth for high-refresh 1080p and 1440p gaming
>Core Clocks: Boost 2527 MHz / Extreme Performance 2535 MHz (via MSI Center)
>SHADOW 2X dual-fan cooling — TORX Fan 5.0 design with ring-arc blades, efficient heatsink, and optimized airflow for quiet operation
>145W TDP — Single 8-pin PCIe power connector, 550W PSU recommended
>Outputs: 3x DisplayPort 2.1b + 1x HDMI 2.1b — Up to 4K 480Hz or 8K 120Hz with DSC, supports up to 4 displays, G-SYNC compatible
>Card Dimensions: 197 x 120 x 40 mm — Weight: 493g | Compact dual-slot design for easy fitment
| Spec | Detail |
|---|---|
| GPU Chip | NVIDIA GeForce RTX 5060 (GB206) |
| Architecture | NVIDIA Blackwell |
| CUDA Cores | 3840 |
| Boost Clock | 2527 MHz (2535 MHz Extreme via MSI Center) |
| Memory | 8GB GDDR7, 128-bit, 28 Gbps, 448 GB/s bandwidth |
| Interface | PCI Express Gen 5 x16 (uses x8) |
| Display Output | 3x DisplayPort 2.1b, 1x HDMI 2.1b (max 4 displays) |
| Max Resolution | 7680 x 4320 (8K) |
| Power Consumption | 145W TDP |
| Power Connector | 1x 8-pin |
| Recommended PSU | 550W |
| Cooling | Dual-fan SHADOW 2X cooler with TORX Fan 5.0 and optimized heatsink |
| RGB | Subtle accents, stealth-focused SHADOW design |
| Model Number | G5060-8S2C |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| G-Sync | Supported |
| Dimensions | 197 x 120 x 40 mm |
| Weight | 493g |
| Warranty | 3 Years MSI India |
| OS Support | Windows 10 / 11 64-bit |
