Motherboard // MSI
MSI PRO H610M-G DDR4 Motherboard
Technical specification
Intel H610 mATX Motherboard for LGA 1700 — DDR4 up to 3200MHz, No Wi-Fi, Intel 1G LAN, PCIe 3.0 x4 M.2 (Chipset), PCIe 4.0 x16, HDMI 2.1 + VGA, COM Port, USB 5Gbps, Frozr AI Cooling, 12th / 13th / 14th Gen Intel Core Ready.
The MSI PRO H610M-G DDR4 is a business-focused H610 mATX for DDR4 memory — offering Core Boost VRM, Frozr AI Cooling, Lightning Gen4 PCIe 4.0 x16, PCIe 3.0 x4 M.2, Realtek 1G LAN, HDMI 2.1 + VGA output, Audio Boost 7.1-CH, USB 5Gbps, COM port, and full Intel 14th/13th/12th Gen Core compatibility. A clean, cost-effective DDR4 platform for professional, office, and everyday Intel builds.
- CPU Support: Intel Core 14th / 13th / 12th Gen, Pentium Gold, Celeron — LGA 1700 socket
- Power Delivery: Core Boost, Memory Boost, Frozr AI Cooling, 1x 8-pin CPU connector
- Storage: M2_1: PCIe 3.0 x4 + SATA (Chipset, 2242/2260/2280); 4x SATA 6G — Note: SATA5 disabled when M.2 SATA used
- Connectivity: No Wi-Fi; Realtek RTL8111H 1G LAN
- USB: Rear — 2x USB 2.0, 2x USB 5Gbps Gen 1 Type-A; Front — 4x USB 2.0, 2x USB 5Gbps Gen 1 Type-A
- PCIe: PCI_E1: PCIe 4.0 x16 (CPU); PCI_E2: PCIe 3.0 x1 (Chipset)
- Audio: Realtek ALC897, 7.1-CH, Audio Boost, up to 192kHz
| Specification | Details |
|---|---|
| Chipset | Intel H610 |
| Socket | LGA 1700 |
| Form Factor | mATX (211 x 243.84 mm) |
| Memory | 2x DDR4 UDIMM, up to 64GB; DDR4 3200(MAX) / 2666 / 2133 MHz (JEDEC); Dual Channel, Non-ECC Unbuffered |
| Memory Standard | Non-ECC Unbuffered DDR4, Dual Channel |
| PCIe Slots | PCI_E1: PCIe 4.0 x16 (CPU); PCI_E2: PCIe 3.0 x1 (Chipset) |
| M.2 Slots | M2_1: PCIe 3.0 x4 + SATA (Chipset, 2242/2260/2280) — 1 slot only; No PCIe 4.0 M.2 |
| SATA | 4x SATA 6G (no RAID on H610); SATA5 disabled when M.2 SATA used |
| LAN | Realtek RTL8111H 1G LAN (no Wi-Fi) |
| Wireless | None |
| Rear USB | 2x USB 2.0, 2x USB 5Gbps Gen 1 Type-A |
| Front USB Headers | 4x USB 2.0, 2x USB 5Gbps Gen 1 Type-A |
| Video Output | 1x HDMI 2.1 (4K@60Hz) + 1x VGA (2048x1536@50Hz / 1920x1200@60Hz) — iGPU only |
| Audio | Realtek ALC897, Audio Boost, 7.1-CH, up to 192kHz |
| Fan Headers | 1x CPU Fan, 1x System Fan |
| RGB | None |
| Extras | Frozr AI Cooling, COM port (JCOM), Click BIOS 5, TPM 2.0 header, Chassis Intrusion header, I/O shield included |
| OS Support | Windows 11 64-bit, Windows 10 64-bit |
