ASRock RX 9060 XT Steel Legend 16GB OC — 2048 Stream Processors, 16GB GDDR6 128-bit 20Gbps, PCIe 5.0 x16, Boost 3320MHz / Game 2780MHz, 150W TDP, 1x 8-pin, 2x DP 2.1a + 1x HDMI 2.1b, 550W PSU Recommended.
The ASRock Radeon RX 9060 XT Steel Legend 16GB OC is a next-gen AMD RDNA 4 GPU with a massive 16GB GDDR6 buffer, purpose-built for high-refresh 1440p gaming and future-proof VRAM headroom. Benchmarks show it is 63% faster than the RX 7600 and RTX 3060 at 1440p, on par with the RTX 5060 Ti 8GB, and even faster than the Ti in VRAM-heavy titles thanks to its double the memory capacity. The Steel Legend triple-fan cooler with Polychrome SYNC ARGB, Ultra-fit heatpipes, Air Deflecting Fin, 0dB fan-stop, LED switch, and premium metal backplate makes it a complete, feature-rich upgrade for performance-focused builds.
-
>AMD RDNA 4 Architecture — 2048 Stream Processors, 32 Compute Units with 3rd-gen RT Cores and 2nd-gen AI Accelerators, 32MB Infinity Cache
>16GB GDDR6 — 128-bit, 20Gbps, 322 GB/s bandwidth — double the VRAM of most competitors at this price point
>Core Clocks: Boost up to 3320 MHz / Game 2780 MHz (OC above reference)
>Steel Legend Triple-Fan Cooler — Striped Ring fans, Ultra-fit heatpipes, Air Deflecting Fin, high-density metal welding, 0dB fan-stop
>Polychrome SYNC ARGB on shroud and backplate with LED On/Off switch
>150W TDP — 1x 8-pin PCIe connector, 550W PSU recommended
>Display Outputs: 2x DisplayPort 2.1a, 1x HDMI 2.1b — up to 3 displays, 8K max resolution
>AMD FSR 4, HYPR-RX, Smart Access Memory, FreeSync Premium, DirectX 12 Ultimate, PCIe Gen 5
| Spec | Detail |
|---|---|
| Brand | ASRock |
| Model Number | RX9060XT SL 16GO |
| GPU | AMD Radeon RX 9060 XT |
| Architecture | AMD RDNA 4 |
| Stream Processors | 2048 |
| Compute Units | 32 |
| AMD Infinity Cache | 32MB |
| Boost Clock | Up to 3320 MHz |
| Game Clock | 2780 MHz |
| Memory | 16GB GDDR6 |
| Memory Speed | 20 Gbps |
| Memory Bus | 128-bit |
| Memory Bandwidth | 322 GB/s |
| Interface | PCI Express 5.0 x16 |
| Display Outputs | 2x DisplayPort 2.1a, 1x HDMI 2.1b |
| Max Resolution | 7680 x 4320 (8K) |
| Max Displays | 3 |
| Power Consumption | 150W TDP |
| Power Connector | 1x 8-pin PCIe |
| Recommended PSU | 550W |
| Cooling | Triple Striped Ring fans, Ultra-fit heatpipes, Air Deflecting Fin, high-density metal welding, 0dB fan-stop |
| Lighting | Polychrome SYNC ARGB (shroud + backplate) + LED On/Off Switch |
| Slot Width | 2.55-slot |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| FreeSync | AMD FreeSync Premium |
| Dimensions | 298 x 131 x 51 mm |
| Net Weight | 967 g |
| Accessories | 1x Quick Installation Guide |
| Warranty | 3 Years ASRock India |
| OS Support | Windows 10 / 11 64-bit |
