ASUS ROG STRIX X870E-E GAMING WIFI ATX Motherboard
ASUS ROG STRIX X870E-E GAMING WIFI ATX Motherboard
Vendor:
AsusSub total
Rs. 47,250.00Couldn't load pickup availability
Estimated deliver 5-7 days
Description
ASUS ROG STRIX X870E-E GAMING WIFI is a top-tier AMD X870E ATX gaming motherboard for Ryzen 7000, 8000 and 9000 Series desktop processors on the AM5 socket. It delivers 18+2+2 power stages, full PCIe 5.0 support for GPU and multiple M.2 slots, five M.2 SSD slots in total, dual USB4 40Gbps ports, Realtek 5Gb Ethernet and Wi‑Fi 7, making it ideal for no-compromise gaming, streaming, content creation and advanced AI PC builds.
Key Features:
- AMD X870E ATX gaming motherboard with AM5 socket for Ryzen 9000 / 8000 / 7000 Series desktop processors.
- 18+2+2 power stage design with large VRM heatsinks for extreme multi-core CPU performance and overclocking.
- 4 x DDR5 DIMM slots, up to 192–256GB dual-channel, supports up to 8000+ MT/s (OC) with AMD EXPO, NitroPath DRAM and ASUS AEMP.
- PCIe 5.0 x16 SafeSlot for latest GPUs plus an additional PCIe 4.0 x16 (x4) slot for high-speed add-in cards.
- Five M.2 slots total: up to three PCIe 5.0 x4 and two PCIe 4.0 x4 NVMe M.2 slots, plus four SATA 6Gb/s ports for extra storage.
- Realtek 5Gb Ethernet for ultra-fast wired networking.
- 2x2 Wi‑Fi 7 with ASUS WiFi Q‑Antenna and Bluetooth 5.4 for best-in-class wireless performance.
- Two USB4 40Gbps Type‑C ports on the rear I/O plus USB 20Gbps Type‑C and multiple USB 10Gbps Type‑A ports.
- AI Overclocking, AI Cooling II, AI Networking II and full ROG Q-Design features (Q‑Release, Q‑Latch, Q‑LED, Q‑Code, Q‑Antenna) for easier building and tuning.
- ROG SupremeFX audio with high-end codec and premium capacitors for immersive gaming and creator audio.
- Signature ROG Strix black design with Aura Sync RGB and multiple Addressable Gen 2 headers.
Specifications:
| Model | ROG STRIX X870E-E GAMING WIFI |
| Chipset | AMD X870E |
| CPU Support | AMD Socket AM5 for Ryzen 9000, 8000 and 7000 Series desktop processors (see ASUS CPU support list). |
| Form Factor | ATX |
| Power Design | 18+2+2 power stages, large VRM heatsinks, ProCool power connectors, alloy chokes and premium capacitors; AI Overclocking, Dynamic OC Switcher, Core Flex. |
| Memory | 4 x DDR5 DIMM slots, max. 192GB (up to 256GB with 64GB DIMMs), dual-channel; supports up to 8000+ MT/s (OC) with Ryzen 9000, 8400+ MT/s (OC) with Ryzen 8000 and 8000+ MT/s (OC) with Ryzen 7000; ECC & non‑ECC unbuffered DIMMs, AMD EXPO, NitroPath DRAM, ASUS AEMP. |
| Expansion Slots |
AMD Ryzen 9000 & 8000 & 7000: - 1 x PCIe 5.0 x16 slot (x16 mode) from CPU AMD X870E chipset: - 1 x PCIe 4.0 x16 slot (x4 mode) |
| Storage |
Total: 5 x M.2 slots and 4 x SATA 6Gb/s ports* AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors: - M.2_1: PCIe 5.0 x4 (NVMe, 2242/2260/2280) - M.2_2: PCIe 5.0 x4 (NVMe, 2242/2260/2280) - M.2_3: PCIe 5.0 x4 (NVMe, 2242/2260/2280) or PCIe 4.0 depending on lane config - M.2_4: PCIe 4.0 x4 (NVMe, 2280) - M.2_5: PCIe 4.0 x4 (NVMe, 2280) 4 x SATA 6Gb/s ports; AMD RAIDXpert2 supports PCIe/SATA RAID 0/1/10 (and RAID 5 on Ryzen 9000 only). *Exact mapping and sharing depend on CPU and installed devices, as per ASUS spec. |
| Graphics Output | 1 x HDMI port (for supported Ryzen APUs) and 2 x USB4 40Gbps Type‑C ports that can output display via DP Alt Mode, depending on GPU/CPU. |
| Networking | 1 x Realtek 5Gb Ethernet (RJ‑45) 2x2 Wi‑Fi 7 (802.11be) with ASUS WiFi Q‑Antenna, supports 2.4/5/6GHz bands and Bluetooth 5.4. |
| Rear USB Ports |
2 x USB4 40Gbps Type‑C 1 x USB 20Gbps Type‑C Multiple USB 10Gbps Type‑A/Type‑C ports (up to eight 10Gbps Type‑A plus one 10Gbps Type‑C, depending on region) Additional USB 2.0 ports for peripherals. |
| Front USB Headers | 1 x USB 20Gbps Type‑C header (PD 3.0 up to 30W), 2 x USB 5Gbps headers (up to 4 extra USB 5Gbps ports), 3 x USB 2.0 headers (up to 6 extra USB 2.0 ports). |
| Audio | ROG SupremeFX HD audio solution with high-end codec (per ASUS spec), isolated audio PCB, premium capacitors and front panel audio support. |
| Cooling & Fan Headers | Large VRM, chipset and M.2 heatsinks; multiple hybrid fan headers, AIO pump header, AI Cooling II and Fan Xpert for fine-grained control. |
| Lighting | Aura Sync RGB lighting, integrated I/O RGB, multiple Addressable Gen 2 headers and RGB header. |
| Operating System | Windows 11 / Windows 10 64‑bit. |
| Warranty | 3 years (ASUS India warranty, typical). |
Ideal For:
Perfect for extreme AM5 gaming rigs, streaming and content creation systems and AI PC builds that demand DDR5, full PCIe 5.0 support, five NVMe slots, dual USB4, 5Gb LAN, Wi‑Fi 7 and the most complete ROG Strix feature set.
