MSI PRO B850M-A WIFI Motherboard

MSI PRO B850M-A WIFI Motherboard

AMD B850 mATX Motherboard for AM5 — 8+2+1 Phase VRM, 60A SPS, Wi-Fi 7 (160MHz), 5G LAN, USB 10Gbps, PCIe 5.0 M.2 Gen5, DDR5 8200+ OC, Supplemental PCIe Power, Silver...

Rs. 32,999.00
Rs. 32,999.00
OFF Sold out
Tax included. Shipping calculated at checkout.

Vendor:

MSI

Type:

Motherboard

Estimated deliver 5-7 days

People are viewing this right now

View full details
Let us know abour your query!
Description
Reviews

AMD B850 mATX Motherboard for AM5 — 8+2+1 Phase VRM, 60A SPS, Wi-Fi 7 (160MHz), 5G LAN, USB 10Gbps, PCIe 5.0 M.2 Gen5, DDR5 8200+ OC, Supplemental PCIe Power, Silver Design, Ryzen 9000 / 8000 / 7000 Ready.

The MSI PRO B850M-A WIFI is the top-tier PRO series mATX motherboard for AMD B850 — combining a clean silver aesthetic with serious features for AI PC workloads and creator builds. Built on an 8+2+1 Duet Rail Power System with 60A Smart Power Stages, it packs Wi-Fi 7 (160MHz, 2.9Gbps, MLO, 4KQAM), Realtek 5G LAN, USB 10Gbps rear Type-C, one CPU-direct PCIe 5.0 x4 M.2 Gen5, two additional PCIe 4.0 M.2 slots, Supplemental PCIe Power 8-pin, and MSI's AI Boost for NPU overclocking — ideal for Ryzen 9000-powered mini workstations and productivity builds.

    >CPU Support: AMD Ryzen 9000 / 8000 / 7000 Series, Socket AM5 >Power Delivery: 8+2+1 Phase VRM, 60A Smart Power Stages, dual 8-pin CPU connectors, Supplemental PCIe Power (8-pin), Core Boost, Memory Boost >Storage: 3x M.2 — M.2_1: PCIe 5.0 x4 (CPU, 2280/2260, Ryzen 9000/7000; PCIe 4.0 x4 Ryzen 8000); M.2_2: PCIe 4.0 x4 (CPU, 2280/2260); M.2_3: PCIe 4.0 x2 (Chipset, 2280/2260); 4x SATA 6G >Connectivity: Wi-Fi 7 (2.4/5/6GHz, 160MHz, up to 2.9Gbps, MU-MIMO, MLO, 4KQAM), Bluetooth 5.4, Realtek RTL8126VB 5G LAN >USB: Rear — 1x USB 10Gbps Type-C, 3x USB 10Gbps Type-A, 3x USB 5Gbps Type-A; Front — 2x USB 5Gbps Type-A, 1x USB 10Gbps Type-C, 4x USB 2.0 >PCIe: PCI_E1: PCIe 5.0 x16 (CPU); PCI_E2: PCIe 4.0 x4 (Chipset); PCI_E3: PCIe 3.0 x1 (Chipset) >Audio: Realtek ALC897, Audio Boost, 7.1-CH, up to 192kHz
Specification Details
Chipset AMD B850
Socket AM5
Form Factor mATX (243.84 x 243.84 mm)
Memory 4x DDR5 UDIMM, up to 256GB; DDR5 8200–5600 (OC) / 5600–4800 (JEDEC) MT/s; 1DPC 1R max 8200+ MT/s / 1DPC 2R max 6400+ MT/s / 2DPC 1R max 6400+ MT/s / 2DPC 2R max 6000+ MT/s OC; Single-sided latches
Memory Standard AMD EXPO, A-XMP, CUDIMM (bypass mode), Dual Channel, Non-ECC Unbuffered, High-Efficiency Mode
PCIe Slots PCI_E1: PCIe 5.0 x16 (CPU); PCI_E2: PCIe 4.0 x4 (Chipset); PCI_E3: PCIe 3.0 x1 (Chipset)
M.2 Slots M.2_1: PCIe 5.0 x4 (CPU, 2280/2260); M.2_2: PCIe 4.0 x4 (CPU, 2280/2260); M.2_3: PCIe 4.0 x2 (Chipset, 2280/2260)
SATA 4x SATA 6G | RAID 0, 1, 10
LAN Realtek RTL8126VB 5G LAN
Wireless Wi-Fi 7 (2.4/5/6GHz, 160MHz, up to 2.9Gbps, MU-MIMO, MLO, 4KQAM), Bluetooth 5.4
Rear USB 1x USB 10Gbps Type-C, 3x USB 10Gbps Type-A, 3x USB 5Gbps Type-A
Front USB Headers 2x USB 5Gbps Type-A, 1x USB 10Gbps Type-C, 4x USB 2.0
Video Output 1x HDMI 2.1 (4K@60Hz) — iGPU only
Audio Realtek ALC897, Audio Boost, 7.1-CH, up to 192kHz
Fan Headers 1x CPU Fan, 1x Combo Fan (Pump/Sys), 3x System Fan, Smart Fan 6
RGB 3x ARGB V2 headers, 1x RGB header, 4x EZ Debug LED, 1x EZ Memory Detection LED
Color Scheme Silver — compatible with white and black builds
Extras AI Boost (NPU OC), EZ M.2 Clip, EZ PCIe Release, EZ Conn header, EZ Antenna, Supplemental PCIe Power (8-pin), Flash BIOS Button, Click BIOS 5, metal backplate
OS Support Windows 11 64-bit
